Mouse and keyboard
Mouse
- left click
- move the cursor — every panel re-cuts through it
- left drag
- what the tool in hand does — window / level with navigate, paint with the brush, and so on
- middle drag
- pan
- right drag
- zoom
- Alt + left drag
- window / level, whatever tool is in hand — width across, level up and down
- Ctrl + left drag
- pan — for a trackpad
- Shift + left drag
- zoom — for a trackpad
- wheel
- previous / next slice — zoom, on the 3-D panel
- drag on 3-D
- turn it; click a tumour to select and measure it
- Shift + wheel
- ten slices at a time
- Ctrl + wheel
- zoom
Keys
- N
- navigate
- P
- pan tool
- Z
- zoom tool
- B / E / G
- brush / eraser / polygon
- [ ]
- brush smaller / larger
- 1 / 3 / 4 / 5
- one panel / MPR / MPR + 3D / 3D alone
- R
- reset the view — fit and re-centre
- F
- maximise — the images take the whole window, tools and lesions float
- + / −
- zoom in / out
- 0
- 1:1 — one pixel per voxel
- ↑ ↓ or Page Up/Down
- previous / next slice
- Home / End
- first / last slice
- I
- invert grey
- M
- show or hide the mask overlay
- Ctrl + S
- save
- ? or H
- this sheet
- Esc
- close the sheet; then finish an outline; then put every tool down; then, maximised, come back. One press per step
What each control is for
Drawing
- ✛ navigate
- click moves the cursor, drag windows the image
- ✥ pan
- move the picture inside the panel; the cursor stays on the anatomy
- ⌕ zoom
- magnify about the middle of the panel
- ⬡ polygon
- click a boundary point by point; Esc fills it in. Click an existing mask to pull its outline up as amber draggable points and Esc redraws it. Axial only
- click, no tool
- with the tools down, clicking a mask picks it up: it becomes an outline and the polygon tool comes with it
- Del
- discard the outline, or — if a mask was picked up — remove it from this slice
- Shift + Del
- remove the whole three-dimensional lesion, not just this cross-section
- ● brush
- paint the mask, in millimetres of patient
- ○ eraser
- the same brush, taking mask away
- brush
- its diameter — a size, so it means the same at every zoom
The stack
- 1 / 3 / 4 / 5
- one panel · MPR (multiplanar reformation — axial, coronal and sagittal at once, through one cursor) · MPR with 3-D · 3-D alone
- window
- the grey ramp the SLICES use. W is the WIDTH of the Hounsfield range spread across black-to-white, L the LEVEL at its middle. Narrow makes a small difference visible; the panel shows both, and left-drag changes them
- Reset view
- refit and re-centre every panel
- 1:1
- one screen pixel per voxel — the acquisition's own resolution
- Mask
- hide the overlay to see the slice as acquired, then bring it back
- phase bar
- plain · arterial · venous · delayed. The mask lives on the venous series, so the brush is off on the others
The 3-D view
- Liver view
- everything at once for a portal-venous liver: solid, 80–160 HU, low opacity
- projection
- how the samples along each ray are combined. solid shows an organ · MIP (maximum intensity projection) the brightest thing along each ray · MinIP the dimmest · mean the average, and the only one whose greys are still Hounsfield units
- 3D band
- tissue outside this range of HU (Hounsfield units — the CT density scale, where water is 0 and air is −1000) is not in the reconstruction at all. Venous liver is ~105–117 HU; muscle 40–60; bone 250+
- opacity
- how much a millimetre of tissue stops the ray. Lower sees deeper into the organ
- cut
- discard the near side, in centimetres. The body wall and the liver are the same tissue by HU, so no band can separate them — this is what gets past it
- lesion list
- click a row to light that tumour and jump to it; click again to clear
The case
- Save
- write the mask. Your ROLE decides which artifact it becomes
- Mark done
- finish the case. Reopening is allowed and recorded
- Reset
- discard your work and start from what you started with
- ⛶ Full
- the images take the whole window; tools and lesions float, and drag. Esc twice comes back
